MLX75027 | Automotive VGA Time-of-Flight Sensor
MLX75027
The MLX75027 automotive VGA Time-of-Flight (ToF) sensor provides a complete Time-of-Flight sensing solution with full VGA depth map resolution up to 135 distance frames per second.
Overview
The MLX75027 automotive Time-of-Flight sensor supports up to VGA resolution. The sensor, alongside the 90 nm BSI VGA pixel array, provides the control signals for the illumination unit and has a MIPI CSI-2 high speed serial interface to stream data to the host processor.
Thanks to a simple supply system, with only three positive voltage domains, the sensor simplifies the design of the supply unit and together with a low power dissipation allows a very compact 3D camera.
The MLX75027 supports up to 100 MHz illumination modulation frequency, which makes it well suited for VCSELs illumination and has a built-in temperature sensor.
The EVK75027 evaluation kit is available to evaluate the MLX75027 automotive VGA ToF sensor.
Features
- Support both 850 and 940 nm wavelength
- Full VGA resolution image acquisition up to 135 distance frames per second
- Integrated light source control with up to 100 MHz modulation frequency
- MIPI CSI-2 serial camera interface
- Integrated temperature sensor
